Catalog 111 • Page 35
?????
6050 (1") Series
11810 (
3
/
4
") Series
JABSCO
Bronze (
3
/
4
") and Plastic (
5
/
8
") Series
JABSCO
Bronze (
3
/
4
") Compact Series
JABSCO
motorized FLEXIBLE IMPELLER
JABSCO
1.5 - 10 GPM, Compact Sizes, in AC and Dc Voltages
The 236XX series is the latest generation of Jabsco’s self-priming bronze Puppy
pumps utilizing fewer wearing parts. This series comes standardwith Nitrile impeller
and ignition protected motors. The 12210-0001 comes with a 6 foot cord and is
especially compact for a 115 vac pump requiring a mounting envelope of only 3
5
/
8
" high, 4" wide x 6
7
/
8
" long.
5 - 9 GPM, COMPACT SIZES, IN AC AND DC VOLTAGES
This series of Jabsco self-priming bronze pumps have been the workhorses of the
industry for over 40 years. Originally referred to as theWater Puppy (DC bronze series)
and Sturdy Puppy (AC bronze series), these rugged medium flow pumps will lift 4 feet
vertically and maintain a prime of up to 15 feet. See
for service parts.
9.5 - 11.2 GPM,
1
/
2
HP, IN AC AND DC VOLTAGES
The Jabsco 11810 series comes in AC and DC voltages, will lift up to 10 feet
and maintain a prime of up to 20 feet. Their solid brass housings are externally
threaded for
3
/
4
" male garden hose thread and internally for
1
/
2
" fpt. These pumps
are often used in bilge, washdown and general transfer applications. See
for service parts.
15.5 - 23 GPM,
3
/
4
HP, IN 115 VOLTS AC
The 6050 series pumps by Jabsco is their highest volume close-coupled pump
moving up to 23 gpm, lifting water up to 10 feet and maintaining a prime of up to
22 feet! They are available with an open drip-proof or totally enclosed fan cooled
motor. An optional vacuum switch can be installed to prevent dry running impeller
damage. See
for service parts.
Model
Max
GPM at Feet of Head
Port
Number
Volts
Amps
GPM
6
13
20
Sizes
JE 23620-4003 12 vdc
5
1.5
1.5
1.3
1.1
3
/
4
" Barb
JE 23620-4103 24 vdc
2.5
1.5
1.5
1.3
1.1
3
/
4
" Barb
JE 23670-4003 12 vdc
13
3.4
3.0
2.5
1.9
3
/
4
" Barb
JE 23670-4103 24 vdc
7
3.4
3.0
2.5
1.9
3
/
4
" Barb
JA 23610-3003 12 vdc
21
10
10
9
8.4
1” Barb
JA 12210-0001 115 vac
-
3.4
3.4
3.2
2.9
3
/
4
” Barb
Model
Pump Body
Max GPM at Feet of Head
Port
Number
Construction Volts Amps GPM
10
20
30
Sizes
JA 18660-0121
Bronze
12 vdc
8
6.3
5.4 4.2
2.8
1
/
2
" FPT and
3
/
4
" GHT
JA 18670-0123
Bronze
12 vdc 11.5
9
8.4 7.7
6.9
1
/
2
" FPT and
3
/
4
" GHT
JA 18670-0943
Bronze
24 vdc
5
9
7.3 6.8
5.8
1
/
2
" FPT and
3
/
4
" GHT
JA 18610-0001
Bronze
115 vac
–
6.5
6.0 5.3
4.2
1
/
2
" FPT and
3
/
4
" GHT
JA 12560-0001
Plastic
12 vdc
7
5.0
4.6 3.7
1.7
5
/
8
" Slip-on Hose
JA 12290-0001
Plastic
115 vac
–
5.8
5.8 5.0
3.8
5
/
8
" Slip-on Hose
Model
Motor
Max GPM at Feet of Head
Port
Number
Enclosure Volts Amps GPM
10
20
30
Sizes
JA 11810-0003
Open
115 vac
–
9.5
9.5 8.1
6.8
1
/
2
" FPT and
3
/
4
" GHT
JA 11810-0013 Enclosed 115 vac
–
9.5
9.5 8.1
6.8
1
/
2
" FPT and
3
/
4
" GHT
JA 11810-0121 Enclosed 12 vdc
28
11.2 11.2 10.5 9.4
1
/
2
" FPT and
3
/
4
" GHT
JA 11810-0241 Enclosed 24 vdc
14
11.2 11.2 10.5 9.4
1
/
2
" FPT and
3
/
4
" GHT
Model
Motor
Max
GPM at Feet of Head
Port
Number
Enclosure
Volts
GPM
10
20
30
60
Sizes
JA 6050-0003
Open
115 vac
23.0
23.0 22.0 19.5 15.5
1" FPT
JA 6050-0013
Enclosed
115 vac
23.0
23.0 22.0 19.5 15.5
1" FPT
