Page 34 • Catalog 111
727-446-1656 • 1-800-446-1656 •
305M (
3
/
4
") and 405M (1") Series
OBERDORFER
3
/
4
" Run Dry Series
jabsco
3
/
4
" Bronze Series
OBERDORFER
3
/
4
" Bronze or Plastic Series
proven / simer / Flotec
motorized flexible impeller
6.5 – 12.5 GPM,
1
/
10
-
1
/
3
HP, IN AC AND DC VOLTAGES
The Oberdorfer 201 series bronze rubber impeller pumps are self-priming and have
a choice of Neoprene or Nitrile (Buna-N) impeller materials. They are available in
115 vac, 12 vdc, 24 vdc, and 32 vdc. Each pump is threaded externally with a
3
/
4
"
garden hose and internally with a
3
/
8
" npt. Below are a few of the pump and motor
combinations available. See
for parts.
Model
Port
Number
Volts
Sizes
0
10
20
30
40
OB N211D-04-D28
115 vac
3
/
4
" GHT
6.5
6.2
6
5.5
4.7
OB N211M-F34
115 vac
3
/
4
" GHT
12.5 12.1 11.5
11
10
OB N201D Series
12/24/32 vdc
3
/
4
" GHT
7
6.7
5.5
3
.3
GPM at Feet of Head
8 – 11 gpm, dry running in DC VOLTAGES
These "dry running" flexible impeller pumps are self-priming (up to 10 feet dry) and
dry running (up to 30 minutes after initial priming). The impeller and seal material
is Nitrile (Buna), the shaft is stainless steel and the pump housing is bronze.
Model
Port
GPM at Feet of Head
Number
Volts
GPM
Sizes
11
23
34
JE 23920-2403
12 vdc
8
3
/
4
" FPT
8
5
—
JE 23920-2503
24 vdc
8
3
/
4
" FPT
11
9
8
JE 23920-2213
12 vdc
11
3
/
4
" FPT
8
5
—
JE 23920-2313
24 vdc
11
3
/
4
" FPT
11
9
8
5 – 10 GPM, Compact Size, Ac AND dc voltages
These Proven, Simer (Mini-Vac) and Flotec pumps are economical and compact. They
are ideal for waterbed draining, portable self-priming sump and water transfer.
The Proven models have a chrome plated bronze pump head while the Simer and
Flotec pumps utilize a non-metallic head with stainless steel wearplates.
Model
Port
Housing
Max
Number
Brand
Volts
Sizes
Material
GPM
PR 360-115V
Proven
115 vac
3
/
4
" GHT
Chrome/Bronze
6
PR 365-12V
Proven
12 vdc
3
/
4
" GHT
Chrome/Bronze
5
SM M-40
Simer
115 vac
3
/
4
" GHT
Plastic/Stainless
6
SM BW85P*
Simer
12 vdc
3
/
4
" GHT
Plastic/Stainless
10
FLT FP0F360AC*
Flotec
115 vac
3
/
4
" GHT
Plastic/Stainless
6
Model
Motor
Port
Number
Volts
Phase HP Enclosure Sizes
0 20 40 60 80
OB 305M-C75
12 vdc
1
/
4
TENV
3
/
4
" FPT
8 6.4
3
–
–
OB 305M-8-10F18BCT 115/230 vac
1
1
/
3
TEFC
3
/
4
" FPT
12 10.5 9.2 6.7 3.0
OB 305M-8-30F18BCT 230/460 vac
3
1
/
3
TEFC
3
/
4
" FPT
12 10.5 9.2 6.7 3.0
OB 305M-8-xxF18BCT 12 vdc or 24 vdc
1
/
3
TEFC
3
/
4
" FPT
12 10.5 9.2 6.7 3.0
OB 405M-4-M26
115/230 vac
1
3
/
4
ODP
1" FPT*
25 24
22
–
–
OB 405M-4-N26
115/230 vac
1
1
ODP
1" FPT*
25 24
22
17 11
OB 405M-4-10N18BCT 115/230 vac
1
1
TEFC
1" FPT*
25 24
22
17 11
OB 405M-4-30N18BCT 230/460 vac
3
1
TEFC
1" FPT*
25 24
22
17 11
OB 405M-4-xxN18BCT 12 vdc or 24 vdc
1
TEFC
1" FPT*
25 24
22
17 11
GPM at Feet of Head
8 – 25 GPM,
1
/
3
- 1 HP, IN AC AND DC VOLTAGES
These Oberdorfer bronze rubber impeller pumps are self-priming and have a choice of
Neoprene or Nitrile (Buna-N) impellers. They are available in single and three phase, 50
and 60 Hz, 12 and 24 vdc, ODP, TEFC, and explosion proof. See
for parts.
*405M Series also has 1
1
/
2
" slip-on ports.
* Includes a 6' garden hose and PUD-L-SCOOP suction attachment.
