Catalog 207 • Page 95
15 – 35 GPM, EXPLOSION PROOF,
DRUM AND TANK MOUNT IN AC AND DC
These pumps by Fill-Rite come with a 2" bung adaptor, built-in check valve, 12' x
3
/
4
" diameter
buna hose with aluminum nozzle for unleaded gas. The 12 and 24 vdc versions also come
with an adjustable suction tube (22" to 40"), which is available as an option on the 115 vac
model. Each pump is protected by a thermal overload. The AC model is rated continuous
duty while the DC models are rated at 30 minutes continuous duty. Bio-Diesel compatible
models available.
13 GPM, EXPLOSION PROOF,
DRUM AND TANK MOUNT IN 115 VAC
This economical version of the Fill-Rite FR-700 comes with a 10' x
3
/
4
" diameter hose, discharge
nozzle and 1" adjustable polymer suction pipe. The SD602 will operate up to 30 minutes
continuously with its
1
/
4
hp, UL listed, thermally protected, explosion proof motor.
HAND OPERATED FUEL PUMPS FOR DRUM AND TANK MOUNT
Fill-Rite manufactures piston and rotary vane hand operated fuel pumps. Both styles
come with a 2" bung adaptor, 8' discharge hose and nozzle, and an adjustable suction tube
(22" to 40"). Pump outlets are
3
/
4
" FPT, inlets are 1" FPT, and their nozzles are constructed
of non-sparking aluminum.
MECHANICAL AND ELECTRONIC FUEL METERS
These fuel meters will handle gasoline, diesel, kerosene and other fuels. Upgraded
versions of these meters are available that are compatible with many chemicals including
insecticides, fertilizers, acids, caustics and other industrial or agricultural fluids. Each
meter has a counter, reset and threaded ports. Not for use in fuel resale installations.
Model
Voltage
GPM
Mounting
Weight
Fill-Rite 1210C
12 vdc
15
2" Bung
35
Fill-Rite 2410C
24 vdc
15
2" Bung
15
Fill-Rite 700V Series
115 vac
20
2" Bung
45
Fill-Rite 300V Series
115 vac
35
2" Bung
88
Model
Voltage
GPM
Mounting
Weight
Fill-Rite SD602
115 vac
13
2" Bung
31
Model
Description
Mounting
Weight
Fill-Rite FR-152
5 Strokes per Gallon
2" Bung
15
Fill-Rite FR-112
10 Revolutions per Gallon
2" Bung
17
Model
Type
Max Flow
Max Display
Port Size
FR 807C
Mechanical
20 gpm
99.9 Gallons
3
/
4
" NPT
FR 807C-1
Mechanical
20 gpm
99.9 Gallons
1" NPT
FR 901
Mechanical
40 gpm
999.9 Gallons
1" NPT
GPI 01A31GM
Electronic
30 gpm
9999.9 Gallons
1" NPT
FR 820
Electronic (not shown)
20 gpm
99.9 Gallons
1" NPT
Mechanical
GASOLINE, KEROSENE AND DIESEL PUMPS
FILL-RITE
115 vac, 12 vdc and 24 vdc
FILL-RITE
115 vac
FILL-RITE
Piston, Rotary Hand Operated
FUEL METERS
