Page 6 • Catalog 111
727-446-1656 • 1-800-446-1656 •
flooded suction & self-priming centrifugal
oberdorfer
300B / 750B Self-Primer
UP TO 5500 GPH, 264,000 BTU in BRONZE
Oberdorfer’s 300B and 750B series self-priming bronze centrifugal pump will lift up to 20
feet and are available with stainless or monel drive shaft sleeves. They come standard with
115/230 vac, open drip proof motors. Additional models are available in three phase, 50 Hz,
TEFC, IEEE-45 and other custom configurations. See
for service parts.
Model
Shaft
Ports
Hz.
HP
GPH at Feet of Head
Max
Number
Material
5'
10' 15' 20'
Head
OB 300B-F13
Stainless
1" FPT
60
1
/
3
1200 920 840 680
35'
OB 300B-1-F26
Stainless/Monel
1" FPT
60
1
/
3
1200 920 840 680
35'
OB 300B-10J36BJ-50/60-316
316SS
1" FPT 50/60
1
/
2
1200 920 840 680
35'
OB 750B Series
Stainless/Monel 1
1
/
2
" FPT 60
1
1
/
2
5520 5520 5520 5520
86'
up to 18,000 gph, 864,000 btu in cast iron or bronze
MP’s “Flomax” series centrifugals isolate the motor shaft from contact with raw water with
the use of a stainless steel impeller shaft extension. They come standard with 115/230
vac, open drip proof motors. Additional models are available in three phase, 50 Hz, TEFC,
IEEE-45 and other custom configurations. See
for service parts.
Model Series
HP Range
Port Size
GPH Flow Range
Max Head
MP FM5 Series
1
1
/
2
- 3
1
1
/
2
" FPT
1200 - 7200
95'
MP FM8 Series
1
1
/
2
- 3
2" FPT
1200 - 8400
93'
MP FM10 Series
5 - 7
1
/
2
2" FPT
1800 - 12,600
130'
MP FM15 Series
5 - 7
1
/
2
3" FPT
1800 - 18,000
130'
Shurflo
Flooded Suction
UP TO 6,480 GPH, 310,000 BTU in Bronze
Shurflo (formerly Sherwood) close-coupled bronze pumps continuously produce high flow
rates under low-head conditions. Designed for continuous low-pressure circulation where
there is no suction lift or where self-priming is not required. The bronze impellers are semi-
open and clog resistant. Discharge port can be rotated at 90 degree intervals.
Model
Shaft
Hz.
Port
GPH at Feet of Head
Max
Material
HP
Size
5'
15'
30'
50'
Head
SH COMBB22
Stainless
60
1
/
2
1 
1
/
4
" x 1"
3300 3000 2700 1980
42'
SH COMBB33
Stainless
60
3
/
4
1 
1
/
4
" x 1"
4320 4080 3780 3180
55'
SH COMBB44
Stainless
60
1
1 
1
/
2
" x 1 
1
/
4
"
6480 6240 5880 5160
58'
mp
Flomax Self-Primer
UP TO 1200 GPH, 48,000 BTU IN 316 CAST STAINLESS
The “Primetime” mini self-primer will not air-lock. It is ideal for any air conditioning or
refrigeration system that is prone to air-lock or requires a suction lift. This rugged cast 316
stainless steel pump comes equipped with a carbon/ceramic mechanical seal
3
/
4
" x
3
/
4
" FPT
ports, and solid 316 stainless steel impeller. 115/230v version comes with a 6' cord with
plug. Also available with a hydraulic motor drive.
Model
Hz.
Port
GPH at Feet of Head
Max
Number
Size
5'
10'
15'
20'
25'
Head
DP Primetime 115/230v
50/60
3
/
4
" FPT
1260 1110
900
570
300
24'
DP Primetime 12v
DC
3
/
4
" FPT
1110
820
510
18.5'
DP Primetime 24v
DC
3
/
4
" FPT
1110
820
510
18.5'
DP Hyd-PT
Hyd
3
/
4
" FPT
*see note
52'
primetime
Mini Self-Primer
*Hydraulic performance varies by hydraulic oil flow and pressure.
