Page 70 • Catalog 111
727-446-1656 • 1-800-446-1656 •
groco 4", 5" and 6" Strainers
Features:
• No inside tie rod
• O-Ring seals
• Bronze castings
• Choice of Lucite sight glass
or bronze sleeve
• Spin-off cover for easy filter
basket access
SE SERIES
Application:
For high power engines with 4" or larger raw water intake which require high flow
rates and low restriction.
DRY
MODEL
PLUMBING
WEIGHT
RATIO
(LBS.)
SE-4000
4" NPT
97
ASE-4000
4" NPT
121
SEF-4000
4" Flange
118
ASEF-4000
4" Flange
142
SEF-5000
5" Flange
134
ASEF-5000
5" Flange
158
SEF-6000
6" Flange
147
ASEF-6000
6" Flange
171
A
B
C
D
E
F
10:1
18.5
–
–
3.00
13.25
–
10:1
18.5
9.00
7.5
–
–
8.05:1 19.0
10.0
8.5
–
–
6.7:1
19.5
11.0
9.5
–
–
(INCHES)
FLOW RATE vs. PRESSURE DROP
PRESSURE DROP (IN. HG)
4000 Series
5000 Series
6000 Series
FLOW RATE (GPM)
0
50
100
150
200
250
300
.5
1.0
1.5
2.0
2.5
3.0
ASEF with Flanged Ports
and Bronze Enclosure
groco
SEF with Flanged Ports
groco
Note:
• Dotted lines apply to SEF Models only.
• “A” for SE Models refers to the top of the cap.
• “A” for SEF Models refers to the top of the flange.
• “Ratio” means open screen area to pipe ratio with
standard basket.
• Standard basket .007" diameter holes. (.125" and
.188" holes are optional)
5
/
8
"
bolts
3
/
4
"
bolts
3
/
4
"
bolts
Dimensions
and Specifications
SE with NPT Threaded Ports
groco
