Catalog 111 • Page 139
westerbeke
WESTERBEKE
Flange Mount
SHERWOOD
Flange Mount
SHERWOOD
Flange Mount
Westerbeke # 24143
Westerbeke # 16423
Part No.. ..........Description............. Qty
810B................Impeller.................. 1
05-08-130..........Ball Bearing.............. 2
05-04-114..........Cam Screw............... 1
05-01-120..........Cam Screw Washer. .... 1
05-29-139..........Seal....................... 2
01-45955...........Seal Spacer.............. 1
01-42389...........Cam....................... 1
01-45284...........Gasket.................... 1
01-45282...........End Cover................ 1
05-04-642..........Cover Screw............. 6
WB 34460..........Shaft...................... 1
05-34-131..........Snap Ring. ............... 1
WB 30326..........Mounting Gasket........ 1
33636MNK. ........Minor Service Kit........ 1
33636MJK..........Major Service Kit. ...... 1
Part No.. ......... Description............. Qty
10077K............ Impeller. ................. 1
11628.............. Lip Seal................... 2
11882.............. Shaft. ..................... 1
10285.............. Cam. ...................... 1
10286.............. Gasket. ................... 1
11518.............. Carbon Bushing.......... 1
10093.............. Impeller Key. ............ 1
7070............... Slinger. ................... 1
12863.............. Snap Ring................. 2
10593.............. End Cover. ............... 1
10195.............. Cam Screw. .............. 1
13293.............. Cover Screw.............. 6
WB 30326......... Mounting Gasket. ....... 1
H-70MNK.......... Minor Service Kit........ 1
H-70MJK. ......... Major Service Kit........ 1
Part No.. ..........Description............. Qty
9959K. .............Impeller.................. 1
9919................Cover Screw............. 4
12444...............Shaft...................... 1
4432................Key........................ 1
12220...............End Cover................ 1
10072...............Cam....................... 1
10515C.............Cam Screw............... 1
11360A. ............Gasket.................... 1
10514C.............Seal....................... 1
12211...............Ball Bearing.............. 2
12710...............Lock Washer............. 4
WB 11143..........Mounting Gasket........ 1
F-85MNK. ..........Minor Service Kit........ 1
F-85MJK............Major Service Kit. ...... 1
33636
H-70
F-85
WESTERBEKE
Flange Mount
Westerbeke # 37431 (Includes
Mounting Gasket and Ports)
Part No.. ......... Description............. Qty
WB 48500......... Impeller. ................. 1
WB 49172......... Shaft. ..................... 1
01-46007-2. ...... End Cover. ............... 1
01-42389.......... Cam. ...................... 1
01-46737-2. ...... Wearplate................ 1
01-42400.......... Pin......................... 1
01-45659.......... Seal Washer.............. 1
05-04-632......... Cover Screw.............. 6
WB 48359......... Cover O-Ring............. 1
05-06-513......... Slinger O-Ring. .......... 1
05-01-120......... Cam Washer.............. 1
05-04-114......... Cam Screw. .............. 1
WB 48254......... Mechanical Seal. ........ 1
05-29139.......... Bearing Seal.............. 1
05-08-503......... Ball Bearing.............. 2
05-34-131......... Snap Ring (LG)........... 1
05-34-501......... Snap Ring (SM)........... 1
WB 30326......... Mounting Gasket. ....... 1
WB 49000*........ Service Kit................ 1
* Service kit includes shaft
48080
JABSCO
Pulley Drive
5320-0011
Westerbeke # 11830
Part No.. .......... Description. ........... Qty
5616-0001. ........ Impeller. ................ 1
91002-0020........ Cover Screw............. 6
11830-0000........ End Cover. .............. 1
2995-0000. ........ Gasket. .................. 1
7895-0001. ........ Cam & Wearplate. ..... 1
92700-0420........ Seal - Water............. 1
93000-0070........ Brg Seal Inner........... 1
92700-0310........ Brg Seal Outer.......... 1
92000-0540........ O-Ring.................... 1
879-0000........... Slinger. .................. 1
91002-0090........ Cam Screw. ............. 1
6020-0000. ........ Shaft & Brg.............. 1
91701-0040........ Snap Ring................ 1
9215-0010. ........ Drive Key. ............... 1
5320-0011MNK.... Minor Service Kit. ...... 1
5320-0011MJK..... Major Service Kit....... 1
SHERWOOD
Flange Mount
Westerbeke # 16432
Part No.. .........Description. ............ Qty
10615K............Impeller.................... 1
1482...............Cover Screw............... 4
12710..............Lock Washer............... 4
1311...............Pin. ......................... 2
10931..............Gasket...................... 1
10929..............Cam......................... 1
10927..............Mechanical Seal........... 1
4259...............Snap Ring (LG). ........... 1
4258...............Snap Ring (SM). ........... 3
12226..............Shaft........................ 1
4257...............Ball Bearing. .............. 1
7070...............Slinger...................... 1
4432...............Key.......................... 1
336. ...............Drain Plug.................. 1
10183..............Cover with Bushing....... 1
06333..............Carbon Bushing. .......... 1
10515C............Screw....................... 1
F-95MNK. .........Minor Service Kit. ........ 1
F-95MJK...........Major Service Kit. ........ 1
F-95
JOHNSON
K 34A / K 34M
10-35187-3
Westerbeke # 45765
Part No.. .......... Description. .......... Qty
808B................ Impeller. ................1
05-29-139.......... Lip Seal. .................2
01-43240........... Gasket. ..................1
01-43239........... End Cover. ..............1
05-04-642.......... Cover Screw.............4
01-45087........... Wearplate. ..............1
01-42400........... Wearplate Pin...........1
05-08-130.......... Ball Bearing.............2
05-34-131.......... Snap Ring (LG)..........1
05-34-501.......... Snap Ring (SM)..........1
01-42910........... Cam. .....................1
05-04-114.......... Cam Screw. .............1
05-01-120.......... Cam Screw Washer.....1
01-45669........... Shaft. ....................1
05-06-521.......... Mounting O-Ring........1
01-43238........... Mounting Clamp........2
05-03-521.......... Key. ......................1
10-35187-3MNK... Minor Service Kit. ......1
10-35187-3MJK.... Major Service Kit.......1
WESTERBEKE
Part No.. ........ Description.............. Qty
808B.............. Impeller. .................. 1
01-46735-1. ..... Shaft....................... 1
01-46739-2. ..... End Cover. ................ 1
01-42910......... Cam........................ 1
01-45542......... Spacer. .................... 1
01-42400......... Pin.......................... 1
01-46676......... Wearplate................. 1
01-45049......... Washer..................... 1
01-46790-01..... Washer..................... 1
0.0279.300. ..... Cover Screw. ............. 4
01-46794-02..... Screw. ..................... 1
0.2173.440. ..... O-Ring. .................... 1
0.2173.432. ..... O-Ring. .................... 1
0.3431.748. ..... Bearing. ................... 2
0.2233.010. ..... Lip Seal (42026).......... 1
09-20-542........ Mechanical Seal (46120).1
0.0371.028. ..... Int Ret Ring. .............. 1
0.0370.012. ..... Ext Ret Ring............... 1
WB 42026MNK... Minor Service Kit......... 1
WB 42026MJK. .. Major Service Kit......... 1
42026 / 46120
