Page 82 • Catalog 207
727-446-1656 • 1-800-446-1656 • www.depcopump.com
HYDRAULICALLY BALANCED DIAPHRAGM
HYDRA-CELL
HYDRA-CELL
D10 Series
HYDRA-CELL
HYDRA-CELL
RPM
0
200
400
600
800 1000 1200 1400 1600
FLOW (GPM)
3.33
3.00
2.66
2.33
2.00
1.66
1.33
1.00
0.66
0.33
1800
M03
F20
12
11
RPM
0
200
400
600
800
1000
1200
1400
1600
FLOW (GPM)
10
9
15
14
13
8
7
6
5
4
3
2
1
1800
D15
D04
0
RPM
200
400
600
800 1000 1200 1400 1600
FLOW (GPM)
10
9
8
7
6
5
4
3
2
1
1800
D10
RPM
0
200
400
600
800
1000
1200
FLOW (GPM)
40
25
20
15
10
5
35
30
D35
H25
UP TO 3.2 GPM, 1500 PSI
• Brass, 316SS,
Hastelloy
®
C
metallic
heads; Polypropylene and Kynar
non-metallic heads
• Buna-XS, Viton
®
-XT, Neoprene, EPDM
or Teflon
®
diaphragm options
• Dry lifts to 5 ft; run-dry capable
• Thin, thick, corrosive or mildly
abrasive liquids can be handled
• C-Face or bare shaft mounted
• - 03 size available in convenient
mono-block style
UP TO 15 GPM, 2500 PSI
• Brass or stainless steel pump heads
• Buna-XS or Viton
®
-XT diaphragm
elastomer options
• Dry lifts to 8'; run-dry capable
• Thin, thick, corrosive or mildly
abrasive liquids can be handled
• C-Face or bare shaft mounted
• Smooth, low pulse fluid delivery
• High pressure performance
UP TO 8.5 GPM, 1000 PSI
Handles Slurries to 300 PSI
• Brass, nickel-plated cast iron, 316SS,
Hastelloy
®
C
metallic heads; Polypro-
pylene and Kynar non-metallic heads
• Buna-XS, Viton
®
-XT, Neoprene, EPDM
or Teflon
®
diaphragm options
• Dry lifts to 7'; run-dry capable
• Thin, thick, corrosive or mildly
abrasive liquids can be handled
• Slurry-duty version available
• C-Face or bare shaft mounted
• Smooth, low pulse fluid delivery
UP TO 37 GPM, 1200 PSI
Handles Slurries to 300 PSI
• Brass, nickel-plated cast iron, 316SS,
Hastelloy
®
C
metallic heads; Polypro-
pylene and Kynar non-metallic heads
• Buna-XS, Viton
®
-XT, Neoprene, EPDM
or Teflon
®
diaphragm options
• Dry lifts to 7'; run-dry capable
• Thin, thick, corrosive or mildly
abrasive liquids can be handled
• Slurry-duty version available
• Smooth, low pulse fluid delivery
H25 and D35 Series
F20 and M03 Series
D04 and D15 Series
